Red Dragon 56 Eco pump

Red Dragon 56 Eco 20w-130w - 11000 ltr. 6.9 mtr. boost

Technical data Red Dragon® 5 ECO pump 130 Watt 11.0 m³:

• 130 Watt/h 6.9 mtr. pressure height
• Speed Adjustable Brushless DC Pump
• Watts, Power Consumption and Revolutions Per Minute (rpm) - Display
• Adjustable in 2 watt steps from 2W to 130W
• Suction side 40 mm (1.25") - pressure side 32 mm (1")
• Operating voltage: 100-240 Volt 50-60 Hz (24V technology)
• Pump protection class: IP 68 control unit: IP 66
• Pump weight without controller: 3.5 kg
• Height suction side: center 75 mm
• Pump size: 130 mm wide / 230 mm length / ~ 190 mm height
• Control unit size: 50mm wide / 100mm length / ~190mm height

Red Dragon 56 Eco pump benefits

• Saltwater Resistant M5 Class 2 Titanium Screws
• Saltwater Resistant Parabolic Rubber Feet for Acoustic Decoupling
• Extremely quiet brushless DC pump with external power electronics
• High efficient technology, sine wave for very quiet operation
• Inlet and outlet complete with DIN connection, compact dimensions
• Easy to use and maintain, low risk of calcification
• Heavy and solid workmanship against vibrations and oscillations
• CE Compliant, Developed and Built
• Quality food from "Mean Well"
• High quality touchscreen display with many extra functions
• (protection against dry running, overheating, overvoltage, blocking, etc.)
• 10V connection/control with 3.5mm TS connector (telephone jack)
• 3m cable between pump and controller
• 1.5m cable plug connection EU/US (Rubber connector)
