Tunze Turbelle master stream 6580

Turbelle® masterstream 6580 – maximum flow for extremely large aquariums The Turbelle® masterstream 6580 is an extremely powerful high-performance propeller pump, designed for applications where exceptionally large aquariums are required.

Turbelle® masterstream 6580 – maximum flow for extremely large aquariums

The Turbelle® masterstream 6580 is an extremely powerful, high-performance propeller pump designed for applications requiring exceptionally strong and wide water flow. Suitable for aquariums larger than 20,000 liters , this pump is widely used in public aquariums, zoos, research institutes, rehabilitation centers, and fish or algae cultivation facilities. It is also available for demanding aquarists with very large reef systems.

Exceptional performance with high efficiency

With an adjustable flow rate from 45,000 to approximately 80,000 liters per hour, the Masterstream 6580 delivers enormous water displacement with a natural, broad flow. Despite this performance, energy consumption remains relatively low thanks to the efficient TUNZE® PM motor technology.

• Flow rate: 45,000 – approx. 80,000 l/h
• Flow velocity: 1.1 – 2.0 m/s
• Power consumption: 130 – 360 W

Fully controllable – includes Wavecontroller 7090

The Turbelle® masterstream 6580 is electronically controllable and comes with the Wavecontroller 7090. In addition, the pump can be controlled via:

• Turbelle® Controller
• Multicontroller
• SmartController 7000

This makes the pump ideal for continuous circulation, wave action and realistic wave and tide simulations.

100% corrosion resistant and seawaterproof

All components are manufactured from high-quality, seawater-resistant materials such as ASA, POM, and reinforced PA6.6. The motor shaft is made of titanium alloy , while the motor and electronics are fully encapsulated in PU resin. This guarantees maximum durability and reliability during long-term use.

• Titanium engine shaft
• PU cast engine and electronics
• PU-coated cable
• Completely corrosion resistant

Integrated control – minimal maintenance requirements

The complete control system is integrated into the engine block. This eliminates the need for external control modules, resulting in:

• Low maintenance
• Optimal water cooling of the engine
• High operational reliability

The pump operates on a safe low voltage of 24 V DC .

Advanced propeller technology

The Masterstream 6580 uses a large, slow-turning performance propeller with a titanium shaft. The pump housing also functions as an intake filter, with an intake surface area almost four times larger than the exhaust. This eliminates the need for an additional intake screen.

• Slow-turning high-performance propeller
• Very large intake surface
• Flow rectifier Ø125 mm with injury protection according to EN 60335-1

Energy efficient for large volumes

Thanks to its high efficiency, the Masterstream 6580 delivers significant energy savings compared to traditional centrifugal pumps. In continuous use, this can result in thousands of euros in annual energy savings for large systems.

Assembly and adjustment

The pump is attached to a 32 mm diameter pipe or rod. Thanks to the 2D adjustment, the flow direction can be precisely adjusted to the aquarium.

• Connection: Ø32 mm
• 2D adjustable
• Corrosion-resistant nuts and bolts

Technical specifications

• Suitable for aquariums: > 20,000 liters
• Power supply: 100–240V / 50–60Hz → 24V DC
• Cable length: 10 m
• Dimensions (L x W x H): 340 x 165 x 227 mm
• Exhaust diameter: Ø125 mm

Summary

The Turbelle® masterstream 6580 is an absolute powerhouse for very large aquariums and professional installations. With extreme flow capacity, complete controllability, high energy efficiency, and a robust, seawater-resistant construction, this is a top-class flow pump for the most demanding applications.
