Theiling Rollermat

This filter relieves the biological filter and (if present) the protein skimmer. The membrane is so fine that it even blocks single-celled parasites such as Ichtyo. Suitable for aquariums and ponds from 300 to 3000 liters.

Theiling Rollermat

This filter relieves the biological filter and (if present) the protein skimmer.
The membrane is so fine that it even blocks single-celled parasites such as Ichtyo.
Suitable for aquariums and ponds from 300 to 3000 liters.

Bottom left the water is pumped into the filter and the clean water flows back through the middle opening. At the top right, a return connection is provided should the filter threaten to overflow.

As the membrane becomes clogged by dirt, the water will rise in the filter until a float 12v. put the motor in motion and let the drum filter run for a while until the water flows through clean filter fleece again, after which the water level drops again.
The dirty membrane is rolled up above the water level on the 2nd roll.

• Efficient mechanical filtration through fine fleece
• Automatic further transport of contaminated fleece
• Easy role change
• The roll has a width of 15 cm and can be one
• Water flow up to 2500L / h - depending on the quality of the water.
• Minimum energy consumption, the average below 0.1W.
• 12V safety voltage

Dimensions: 42 x 45.5 x 23.5 cm (L x H x W).

When installing, 10 cm must be added in height, so that the roll can be changed easily. If placed in a filter tank, the water level may not rise higher than 13 cm in operation.

Membrane rollers are available in 2 different pore sizes:

• Aquarium fleece: 40 g / m², c. 45 m long
• Pond fleece: 20 g / m², 90 m long.

English description

Automatic mechanical Filter for fresh and saltwater aquariums and garden ponds. The Rollermat removes waste particles from the water. Biofilter and protein skimmer are relieved and the result is crystal clear and healthy fish. The water is filtered by a fine fleece, which is automatically renewed from a roll, as soon as it is blocked. The fleece is so small, that single cell parasites like Ichtyo can be retained. With 12 V motor, 4 W.

Dimensions incl. Top: 42 x 45.5 x 23.5 cm
